3315 A-2Z
Outer diameter (D): 160 mm
Inner diameter (d): 75 mm
Width (B): 68.3 mm
Basic dynamic load rating : 176 KN
Basic static load rating: 140 KN
Product Description
Outer diameter (D):
160 mm
Inner diameter (d):
75 mm
Width (B):
68.3 mm
Basic dynamic load rating :
176 KN
Basic static load rating:
140 KN
Limiting speed :
-r/min
Reference speed :
4000 r/min
Fatigue load limit (Pu):
5.5 KN
Shoulder diameter (d2):
95.4 mm
Recess diameter (D2):
2.1 mm
Chamfer dimension (r1,2):
97 mm
Distance side face to pressure point (a):
87 mm
Diameter of shaft abutment (da MIN):
88 mm
Housing abutment diameter (Da):
148 mm
Chamfer dimension (ra):
2 mm
Type:
Closed
Mass:
5.6 kg
