10BGR02S

Outer Diameter (D): 30mm

Inner Diameter (d): 10mm

Width (B): 9mm

Chamfer(rmin): 0.6mm

Chamfer(r1min): 0.3mm

Product Specifications

Outer Diameter (D): 30mm
Inner Diameter (d): 10mm
Width (B): 9mm
Chamfer(rmin): 0.6mm
Chamfer(r1min): 0.3mm
Basic Dynamic Load Rating(Cr): 3.6KN
Basic Static Load Rating(Cor): 1.33KN
Permissible Axial Load(1): 1.6KN
Pt. load application(a): 7.2mm
Limiting Speeds (Grease): 80000rpm
Limiting Speeds (Oil): 110000rpm
Mass(M): 0.032kg
10BGR02S
