50BER10S
Outer diameter (D): 80 mm
Inner diameter (d): 50 mm
Width (B): 16 mm
Chamfer dimension (r): 1 mm
Chamfer dimension (r1): 0.6 mm
Product Description
Outer diameter (D):
80 mm
Inner diameter (d):
50 mm
Width (B):
16 mm
Chamfer dimension (r):
1 mm
Chamfer dimension (r1):
0.6 mm
Basic dynamic load rating :
11.60 KN
Basic static load rating:
9.50 KN
Permissible axial load (1):
16.50 KN
Pt. load application (a):
23.0 mm
Limiting speed (Grease):
18500 rpm
Limiting speed (Oil):
26200 rpm
Mass:
0.281 kg
