25BER19S

Outer Diameter (D): 42mm

Inner Diameter (d): 25mm

Width (B): 9mm

Chamfer(rmin): 0.3mm

Chamfer(r1min): 0.15mm

Product Specifications

Outer Diameter (D): 42mm
Inner Diameter (d): 25mm
Width (B): 9mm
Chamfer(rmin): 0.3mm
Chamfer(r1min): 0.15mm
Basic Dynamic Load Rating(Cr): 5.70KN
Basic Static Load Rating(Cor): 3.40KN
Permissible Axial Load(1): 5.90KN
Pt. load application(a): 12.3mm
Limiting Speeds (Grease): 35900rpm
Limiting Speeds (Oil): 50800rpm
Mass(M): 0.042kg
25BER19S
