25BNR19S
Outer diameter (D): 42 mm
Inner diameter (d): 25 mm
Width (B): 9 mm
Chamfer dimension (r): 0.3 mm
Chamfer dimension (r1): 0.15 mm
Product Description
Outer diameter (D):
42 mm
Inner diameter (d):
25 mm
Width (B):
9 mm
Chamfer dimension (r):
0.3 mm
Chamfer dimension (r1):
0.15 mm
Basic dynamic load rating :
5.95 KN
Basic static load rating:
3.50 KN
Permissible axial load (1):
4.95 KN
Pt. load application (a):
9.9 mm
Limiting speed (Grease):
41800 rpm
Limiting speed (Oil):
59800 rpm
Mass:
0.042 kg
