45BER19S
Outer diameter (D): 68 mm
Inner diameter (d): 45 mm
Width (B): 12 mm
Chamfer dimension (r): 0.6 mm
Chamfer dimension (r1): 0.30 mm
Product Description
Outer diameter (D):
68 mm
Inner diameter (d):
45 mm
Width (B):
12 mm
Chamfer dimension (r):
0.6 mm
Chamfer dimension (r1):
0.30 mm
Basic dynamic load rating :
11.60 KN
Basic static load rating:
8.35 KN
Permissible axial load (1):
14.60 KN
Pt. load application (a):
19.2 mm
Limiting speed (Grease):
21300 rpm
Limiting speed (Oil):
30100 rpm
Mass:
0.125 kg
