4310 ATN9

Outer Diameter (D): 110mm

Inner Diameter (d): 50mm

Width (B): 40mm

Basic Dynamic Load Rating (C): 81.9kN

Basic Static Load Rating (Co): 69.5kN

Product Specifications

Outer Diameter (D): 110mm
Inner Diameter (d): 50mm
Width (B): 40mm
Basic Dynamic Load Rating (C): 81.9kN
Basic Static Load Rating (Co): 69.5kN
Fatigue load limit(Pu): 2.9kN
Reference speed (r/min): 10000r/min
Limiting Speed(r/min): 5300r/min
Shoulder Diameter (d1) : 70mm
Shoulder diameter (D1) : 90mm
Chamfer dimension (r1,2 min): 2mm
Mass (kg): 1.7kg
4310 ATN9
