6024 N
Outer diameter (D): 180 mm
Inner diameter (d): 120 mm
Width (B): 28 mm
Basic dynamic load rating : 88.4 KN
Basic static load rating: 80 KN
Product Description
Outer diameter (D):
180 mm
Inner diameter (d):
120 mm
Width (B):
28 mm
Basic dynamic load rating :
88.4 KN
Basic static load rating:
80 KN
Fatigue load limit (Pu):
2.75 KN
Reference speed :
7500 r/min
Limiting speed :
4800 r/min
Shoulder diameter (d1):
139 mm
Shoulder diameter (D1):
-
Recess diameter (D2):
166 mm
Diameter of snap ring groove (D3):
173.66 mm
Outside diameter of snap ring (D4):
192.9 mm
Width of snap ring groove (b):
3.5 mm
Width of snap ring (f):
3.1 mm
Chamfer dimension (r1,2):
2 mm
Mass:
2.2 kg
