6219 N
Abutment and fillet dimensions (Da): 170 mm
Inner diameter (d): 95 mm
Width (B): 32 mm
Basic dynamic load rating : 114 KN
Basic static load rating: 81.5 KN
Product Description
Abutment and fillet dimensions (Da):
170 mm
Inner diameter (d):
95 mm
Width (B):
32 mm
Basic dynamic load rating :
114 KN
Basic static load rating:
81.5 KN
Fatigue load limit (Pu):
3 KN
Reference speed :
8000 r/min
Limiting speed :
5000 r/min
Shoulder diameter (d1):
118 mm
Shoulder diameter (D1):
-
Recess diameter (D2):
152 mm
Diameter of snap ring groove (D3):
163.65 mm
Outside diameter of snap ring (D4):
182.9 mm
Width of snap ring groove (b):
3.5 mm
Width of snap ring (f):
3.1 mm
Chamfer dimension (r1,2):
2.1 mm
Mass:
2.7 kg
