211 ZNR
Outer diameter (D): 100 mm
Inner diameter (d): 55 mm
Width (B): 21 mm
Basic dynamic load rating : 48.4 KN
Basic static load rating: 44 KN
Product Description
Outer diameter (D):
100 mm
Inner diameter (d):
55 mm
Width (B):
21 mm
Basic dynamic load rating :
48.4 KN
Basic static load rating:
44 KN
Fatigue load limit (Pu):
1.86 KN
Reference speed :
12000 r/min
Limiting speed :
7000 r/min
Shoulder diameter (d1):
69 mm
Recess diameter (D2):
89.4 mm
Diameter of snap ring groove (D3):
96.8 mm
Outside diameter of snap ring (D4):
106.5 mm
Width of snap ring groove (b):
2.7 mm
Width of snap ring (f):
2.46 mm
Chamfer dimension (r1,2):
1.5 mm
Mass:
0.66 kg
