310 NR
Outer diameter (D): 110 mm
Inner diameter (d): 50 mm
Width (B): 27 mm
Basic dynamic load rating : 64.4 KN
Basic static load rating: 52 KN
Product Description
Outer diameter (D):
110 mm
Inner diameter (d):
50 mm
Width (B):
27 mm
Basic dynamic load rating :
64.4 KN
Basic static load rating:
52 KN
Fatigue load limit (Pu):
2.2 KN
Reference speed :
11000 r/min
Limiting speed :
7000 r/min
Shoulder diameter (d1):
68.7 mm
Recess diameter (D2):
95.2 mm
Diameter of snap ring groove (D3):
106.81 mm
Outside diameter of snap ring (D4):
116.6 mm
Width of snap ring groove (b):
2.7 mm
Width of snap ring (f):
2.46 mm
Chamfer dimension (r1,2):
2 mm
Mass:
1.15 kg
