317 2Z
Outer diameter (D): 180 mm
Inner diameter (d): 85 mm
Width (B): 41 mm
Basic dynamic load rating : 147 KN
Basic static load rating: 146 KN
Product Description
Outer diameter (D):
180 mm
Inner diameter (d):
85 mm
Width (B):
41 mm
Basic dynamic load rating :
147 KN
Basic static load rating:
146 KN
Fatigue load limit (Pu):
5.3 KN
Reference speed :
6700 r/min
Limiting speed :
3200 r/min
Shoulder diameter (d1):
112 mm
Recess diameter (D2):
155.4 mm
Diameter of snap ring groove (D3):
-
Outside diameter of snap ring (D4):
-
Width of snap ring groove (b):
-
Width of snap ring (f):
-
Chamfer dimension (r1,2):
3 mm
Mass:
4.6 kg
