318 Z
Outer diameter (D): 190 mm
Inner diameter (d): 90 mm
Width (B): 43 mm
Basic dynamic load rating : 157 KN
Basic static load rating: 160 KN
Product Description
Outer diameter (D):
190 mm
Inner diameter (d):
90 mm
Width (B):
43 mm
Basic dynamic load rating :
157 KN
Basic static load rating:
160 KN
Fatigue load limit (Pu):
5.7 KN
Reference speed :
6300 r/min
Limiting speed :
4000 r/min
Shoulder diameter (d1):
119 mm
Recess diameter (D2):
163.9 mm
Diameter of snap ring groove (D3):
-
Outside diameter of snap ring (D4):
-
Width of snap ring groove (b):
-
Width of snap ring (f):
-
Chamfer dimension (r1,2):
3 mm
Mass:
5.4 kg
