618/9
Outer diameter (D): 17 mm
Inner diameter (d): 9 mm
Width (B): 4 mm
Basic dynamic load rating : 0.761 KN
Basic static load rating: 0.335 KN
Product Description
Outer diameter (D):
17 mm
Inner diameter (d):
9 mm
Width (B):
4 mm
Basic dynamic load rating :
0.761 KN
Basic static load rating:
0.335 KN
Fatigue load limit (Pu):
0.014 KN
Reference speed :
85000 r/min
Limiting speed :
53000 r/min
Shoulder diameter (d1):
11.5 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
14.5 mm
Shoulder diameter (D2):
-
Chamfer dimension (r1,2):
0.2 mm
Mass:
3.4 g
