619/6
Outer diameter (D): 15 mm
Inner diameter (d): 6 mm
Width (B): 5 mm
Basic dynamic load rating : 0.761 KN
Basic static load rating: 0.265 KN
Product Description
Outer diameter (D):
15 mm
Inner diameter (d):
6 mm
Width (B):
5 mm
Basic dynamic load rating :
0.761 KN
Basic static load rating:
0.265 KN
Fatigue load limit (Pu):
0.011 KN
Reference speed :
100000 r/min
Limiting speed :
63000 r/min
Shoulder diameter (d1):
-
Shoulder diameter (d2):
7.5 mm
Shoulder diameter (D1):
-
Shoulder diameter (D2):
13 mm
Chamfer dimension (r1,2):
0.2 mm
Mass:
3.5 g
