60/710 MA
Outer diameter (D): 1030 mm
Inner diameter (d): 710 mm
Width (B): 140 mm
Basic dynamic load rating : 95 KN
Basic static load rating: 2200 KN
Product Description
Outer diameter (D):
1030 mm
Inner diameter (d):
710 mm
Width (B):
140 mm
Basic dynamic load rating :
95 KN
Basic static load rating:
2200 KN
Fatigue load limit (Pu):
31.5 KN
Reference speed :
1000 r/min
Limiting speed :
850 r/min
Shoulder diameter (d1):
811 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
928 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
7.5 mm
Mass:
382 kg
