6072 M
Outer diameter (D): 540 mm
Inner diameter (d): 360 mm
Width (B): 82 mm
Basic dynamic load rating : 442 KN
Basic static load rating: 695 KN
Product Description
Outer diameter (D):
540 mm
Inner diameter (d):
360 mm
Width (B):
82 mm
Basic dynamic load rating :
442 KN
Basic static load rating:
695 KN
Fatigue load limit (Pu):
14 KN
Reference speed :
2400 r/min
Limiting speed :
1900 r/min
Shoulder diameter (d1):
416 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
485 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
5 mm
Mass:
64.5 kg
