618/1120 MA
Outer diameter (D): 1360 mm
Inner diameter (d): 1120 mm
Width (B): 106 mm
Basic dynamic load rating : 741 KN
Basic static load rating: 2200 KN
Product Description
Outer diameter (D):
1360 mm
Inner diameter (d):
1120 mm
Width (B):
106 mm
Basic dynamic load rating :
741 KN
Basic static load rating:
2200 KN
Fatigue load limit (Pu):
26.5 KN
Reference speed :
630 r/min
Limiting speed :
530 r/min
Shoulder diameter (d1):
1201 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
1278 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
6 mm
Mass:
315 kg
