618/1320 MA
Outer diameter (D): 1600 mm
Inner diameter (d): 1320 mm
Width (B): 122 mm
Basic dynamic load rating : 756 KN
Basic static load rating: 3150 KN
Product Description
Outer diameter (D):
1600 mm
Inner diameter (d):
1320 mm
Width (B):
122 mm
Basic dynamic load rating :
756 KN
Basic static load rating:
3150 KN
Fatigue load limit (Pu):
35.5 KN
Reference speed :
480 r/min
Limiting speed :
400 r/min
Shoulder diameter (d1):
1414 mm
Shoulder diameter (D2):
-
Shoulder diameter (D1):
1506 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
6 mm
Mass:
500 kg
