618/950 MA
Outer diameter (D): 1150 mm
Inner diameter (d): 950 mm
Width (B): 90 mm
Basic dynamic load rating : 637 KN
Basic static load rating: 1730 KN
Product Description
Outer diameter (D):
1150 mm
Inner diameter (d):
950 mm
Width (B):
90 mm
Basic dynamic load rating :
637 KN
Basic static load rating:
1730 KN
Fatigue load limit (Pu):
22.4 KN
Reference speed :
800 r/min
Limiting speed :
670 r/min
Shoulder diameter (d1):
1015 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
1084 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
5 mm
Mass:
197 kg
