61888 MA
Outer diameter (D): 540 mm
Inner diameter (d): 440 mm
Width (B): 46 mm
Basic dynamic load rating : 255 KN
Basic static load rating: 440 KN
Product Description
Outer diameter (D):
540 mm
Inner diameter (d):
440 mm
Width (B):
46 mm
Basic dynamic load rating :
255 KN
Basic static load rating:
440 KN
Fatigue load limit (Pu):
8.5 KN
Reference speed :
2200 r/min
Limiting speed :
1800 r/min
Shoulder diameter (d1):
472 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
510 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
2.1 mm
Mass:
22.5 kg
