61892 MA
Outer diameter (D): 580 mm
Inner diameter (d): 460 mm
Width (B): 56 mm
Basic dynamic load rating : 379 KN
Basic static load rating: 570 KN
Product Description
Outer diameter (D):
580 mm
Inner diameter (d):
460 mm
Width (B):
56 mm
Basic dynamic load rating :
379 KN
Basic static load rating:
570 KN
Fatigue load limit (Pu):
10.6 KN
Reference speed :
2000 r/min
Limiting speed :
1600 r/min
Shoulder diameter (d1):
498 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
542 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
3 mm
Mass:
35 kg
