619/4 2Z
Outer diameter (D): 11 mm
Inner diameter (d): 4 mm
Width (B): 4 mm
Basic dynamic load rating : 0.624 KN
Basic static load rating: 0.18 KN
Product Description
Outer diameter (D):
11 mm
Inner diameter (d):
4 mm
Width (B):
4 mm
Basic dynamic load rating :
0.624 KN
Basic static load rating:
0.18 KN
Fatigue load limit (Pu):
0.008 KN
Reference speed :
130000 r/min
Limiting speed :
63000 r/min
Shoulder diameter (d1):
6.1 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
-
Recess diameter (D2):
9.9 mm
Chamfer dimension (r1,2):
0.15 mm
Mass:
0.0017 kg
