619/670 MA
Outer diameter (D): 900 mm
Inner diameter (d): 670 mm
Width (B): 103 mm
Basic dynamic load rating : 676 KN
Basic static load rating: 1500 KN
Product Description
Outer diameter (D):
900 mm
Inner diameter (d):
670 mm
Width (B):
103 mm
Basic dynamic load rating :
676 KN
Basic static load rating:
1500 KN
Fatigue load limit (Pu):
22.4 KN
Reference speed :
1200 r/min
Limiting speed :
1000 r/min
Shoulder diameter (d1):
745 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
825 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
6 mm
Mass:
192 kg
