6236 M
Outer diameter (D): 320 mm
Inner diameter (d): 180 mm
Width (B): 52 mm
Basic dynamic load rating : 229 KN
Basic static load rating: 240 KN
Product Description
Outer diameter (D):
320 mm
Inner diameter (d):
180 mm
Width (B):
52 mm
Basic dynamic load rating :
229 KN
Basic static load rating:
240 KN
Fatigue load limit (Pu):
6.4 KN
Reference speed :
4000 r/min
Limiting speed :
3800 r/min
Shoulder diameter (d1):
226 mm
Shoulder diameter (d2):
-
Shoulder diameter (D1):
274 mm
Recess diameter (D2):
-
Chamfer dimension (r1,2):
4 mm
Mass:
18 kg
