J02508XP0
Inner diameter (d): 25 mm
Outer diameter (D): 41 mm
Width (B): 8 mm
Land diameters (L1): 31.55 mm
Land diameters (L2): 34.42 mm
Product Description
Inner diameter (d):
25 mm
Outer diameter (D):
41 mm
Width (B):
8 mm
Land diameters (L1):
31.55 mm
Land diameters (L2):
34.42 mm
Radial static load:
334 kg
Radial dynamic load:
331 kg
Axial static capacities:
758 kg
Axial dynamic capacities :
469 kg
Static moment:
49 N.m
Dynamic moment:
40 N.m
Limiting speed :
3000 rpm
Torque Max no load :
0.02 N.m
Mass:
0.06 kg
Type:
X
