J07008XP0
Inner diameter (d): 70 mm
Outer diameter (D): 86 mm
Width (B): 8 mm
Land diameters (L1): 76.55 mm
Land diameters (L2): 79.42 mm
Product Description
Inner diameter (d):
70 mm
Outer diameter (D):
86 mm
Width (B):
8 mm
Land diameters (L1):
76.55 mm
Land diameters (L2):
79.42 mm
Radial static load:
757 kg
Radial dynamic load:
549 kg
Axial static capacities:
1894 kg
Axial dynamic capacities :
819 kg
Static moment:
290 N.m
Dynamic moment:
158 N.m
Limiting speed :
1090 rpm
Torque Max no load :
0.07 N.m
Mass:
0.10 kg
Type:
X
