T01-00500NAA
Gear I.D.: 4.172 inch
Outer diameter (D): 5.750 inch
Inner land: 4.898 inch
Outer land: 5.106 inch
Inner bolt circle: 4.563 inch
Product Description
Gear I.D.:
4.172 inch
Outer diameter (D):
5.750 inch
Inner land:
4.898 inch
Outer land:
5.106 inch
Inner bolt circle:
4.563 inch
Number of holes:
14
Outer bolt circle:
5.438 inch
Number of holes:
18
Gear pitch circle diameter:
4.230 inch
Number of teeth (z):
269
